AMC - CD6d CD player
No. 96415531
AMC CD6d tube CD player
Description of the AMC CD6d tube CD player
The AMC CD6d is a tube CD player combining classic and modern technologies. Its design incorporates American-made JAN-Philips tubes and a high-quality Philips transport mechanism.
The AMC CD6d incorporates the best of the CD6 series to offer the highest possible quality.
The device is also made from a sturdy and professional material. Its design is austere but commands respect. Another important feature of this very interesting device is its tube output stage in Class A.
The AMC CD6d model was designed to meet professional-grade performance standards.
and provide a higher value.
High-quality selected components are used throughout the circuit design, with particular emphasis on audio path components to ensure stable and consistent performance.
The high-quality servo transmission and drive system ensures consistent data recovery and unmatched tracking performance.
AMC CD6d tube CD player specifications
Transport Philips
120 mm and 80 mm CD disks
DAC PHILIPS:
2 x NE 5532 N - J 75305 M JNR 136 L
2 x NE 5532 N – J77085 M JNR 136 L
Dynamic range >102 dB
Analog filter Active
Lamps 2 x JAN-Philips 5814A (made in the United States)
Filtering errors 100 dB
Channel Imbalance 100 dB
Weighted signal-to-noise ratio: 113 dB
Total harmonic distortion (0 dB, 1 kHz, A-weighted): 0.0011% (-99.17 dB)
Intermodulation distortion (19 and 20 kHz) dB
Energy consumption: 30 W
Output impedance 120 Ohm
Output signal level (0 dB) 2.2 V
Digital output S/PDIF
Digital output level 0.5 Vpp
Load impedance 75 Ohm
General
Weight: 7 kg
Dimensions: 430 x 300 x 82 mm
Remote Control AMC RC 101
Year of production 1992
The following services are included in the shipping fees:
The entire set will be carefully packaged to secure the shipment for all destinations.
Additional insurance will be taken out.
AMC CD6d tube CD player
Description of the AMC CD6d tube CD player
The AMC CD6d is a tube CD player combining classic and modern technologies. Its design incorporates American-made JAN-Philips tubes and a high-quality Philips transport mechanism.
The AMC CD6d incorporates the best of the CD6 series to offer the highest possible quality.
The device is also made from a sturdy and professional material. Its design is austere but commands respect. Another important feature of this very interesting device is its tube output stage in Class A.
The AMC CD6d model was designed to meet professional-grade performance standards.
and provide a higher value.
High-quality selected components are used throughout the circuit design, with particular emphasis on audio path components to ensure stable and consistent performance.
The high-quality servo transmission and drive system ensures consistent data recovery and unmatched tracking performance.
AMC CD6d tube CD player specifications
Transport Philips
120 mm and 80 mm CD disks
DAC PHILIPS:
2 x NE 5532 N - J 75305 M JNR 136 L
2 x NE 5532 N – J77085 M JNR 136 L
Dynamic range >102 dB
Analog filter Active
Lamps 2 x JAN-Philips 5814A (made in the United States)
Filtering errors 100 dB
Channel Imbalance 100 dB
Weighted signal-to-noise ratio: 113 dB
Total harmonic distortion (0 dB, 1 kHz, A-weighted): 0.0011% (-99.17 dB)
Intermodulation distortion (19 and 20 kHz) dB
Energy consumption: 30 W
Output impedance 120 Ohm
Output signal level (0 dB) 2.2 V
Digital output S/PDIF
Digital output level 0.5 Vpp
Load impedance 75 Ohm
General
Weight: 7 kg
Dimensions: 430 x 300 x 82 mm
Remote Control AMC RC 101
Year of production 1992
The following services are included in the shipping fees:
The entire set will be carefully packaged to secure the shipment for all destinations.
Additional insurance will be taken out.
Era
After 2000
Brand
AMC
Model
CD6d
Multiple Models
No
Condition
Excellent
Nr of items
2
Includes
Remote control
Serial Number
CD6d3201020
Year of Manufacturing
1992
Weight
7 kg
Tested and working
Tested and working/playable
